The EMS-112 is a compact, powerful subwoofer, designed to complement the smaller fullrange products within the EMS Series – especially the EMS-51, EMS-61 and EMS-81X. The optimally-tuned vented enclosure provides excellent transient response and low frequency reproduction without the aid of corrective equalisation. The EMS-112 has the advantage of being completely passive – having both a low-pass filter for the subwoofer itself, and also a seperate high-pass filtered output for fullrange boxes. This makes the EMS-112 a truly self-contained system, enabling subwoofer and fullrange loudspeaker to be run from a single amplifier channel. The enclosure contains a single 4¡± (102mm) voice coil, 12¡± (305mm) high-excursion LF drive unit, and is constructed from premium grade multi-laminate Birch plywood and finished in impact resistant paint. The front of the subwoofer is protected by a rigid steel grille. Two flush handles, rubber feet and mating recesses and an M20 threaded pole adapter are provided for flexibility when in use. Three Neutrik SpeakONTM NL4MP connectors are provided on a recessed panel at the rear – two for input and enclosure link, and a third for the seperate high-pass filtered output. RAL colour matching and weather protection options are also available if required. The EMS-112 can add low frequency power and extension to systems based around any EM Acoustics fullrange product, but is particularly suited to the smaller products within the range. The EMS-112 requires a single amplifier channel capable of delivering 800-1000W RMS into a 8 ohm load. For best results the EM Acoustics AQ-10 or AD-9 amplifiers should be used.
