The M-C12 is the smaller of two new coaxial stage monitors from EM Acoustics – a compact two-way design intended to satisfy the most demanding artist.  The M-C12, and the larger companion M-C15 – are intended not only to be world-class stage monitors, but also to suit today’s rental market by being genuine multi-purpose loudspeakers.

The low-profile enclosure contains a 12” (305mm) neodymium LF drive unit with a coaxial 1.4” (36mm) exit HF compression drive unit, linked via the internal passive crossover network.  Both the LF and HF drive units share the same magnet assembly, reducing overall weight and enclosure profile – making the M-C12 one of the lowest profile 12” stage monitors on the market today at only 316mm (12.4”) tall.  The HF drive unit is coupled to a bespoke constant-directivity waveguide, which produces a 40°H x 60°V dispersion pattern on stage.

The robust enclosure is constructed from premium multi-laminate Birch plywood and is finished in impact resistant textured paint.  The enclosure contains a pair of M8 threaded mounting points in each end for attaching the optional flying hardware, and a 35mm polemount is hidden discreetly inside one of the handles to allow stand mounting.  When used in this way as a powerful front-of-house loudspeaker, the waveguide produces a 60°H x 40°V coverage pattern.

The M-C12 is supplied in black as standard, however RAL colour matching and weather protection options are also available if required.  The front of the loudspeaker is protected by a rigid 2mm steel grille backed with acoustically transparent fabric and supported by steel braces for additional strength.  Two flush handles and protective floor skids complete the hardware package, and a single NL4 connector is provided on each end within a sculpted recess for discreet cabling.

The M-C12 requires a single amplifier channel, and should be used with professional power amplifiers capable of delivering 750-1000W RMS into an 8-ohm load.  For best results, the EM Acoustics AQ-3 or AQ-10 power amplifiers should be used.
